Here are Precautions for storage of glass wool insulation

Here are Precautions for storage of glass wool insulation

1. Pay attention to rainproof and do not construct in rainy days.

2. When used for refrigeration, a moisture-proof layer must be added. At particularly low temperatures, resin free glass wool should be used as thermal insulation material, and its moisture-proof layer must also be fireproof.

3. When the temperature exceeds a certain temperature (such as 200 ), appropriate external protection measures shall be added during the insulation process to keep the thickness and bulk density of glass wool insulation board unchanged.

4. Glass wool insulation board is used for large-diameter and flat wall equipment. When the temperature exceeds 200 degrees, insulation nails must be added (the spacing is about 400mm) and the external protection shall be close.

5. Equipment, insulation nails and pipes requiring insulation can be coated with appropriate coatings to facilitate corrosion prevention. In addition, leakage should be prevented. This can achieve better results.

6. The finished glass wool insulation board is vulnerable to mechanical wear under outdoor insulation conditions. Metal or plastic packaging shall be used, and then pay attention to the joints. When sealing joints, glue shall be added for sealing. The local stacking area of the wrapping layer shall not be less than 100mm

7. When the thermal insulation object is placed at 90 degrees and has a certain height, the thermal insulation layer of glass wool thermal insulation board must have positioning pins or support rings, and the spacing shall not exceed 3M, so as to prevent the thermal insulation material from sliding downward during vibration.

8. In order to achieve the purpose of relatively small heat loss, the joint between glass wool insulation board and felt must be closely connected. If there are multiple layers of insulation, the cross joints need to be intertwined to avoid the formation of thermal bridges. When maintaining low temperature, the cold bridge must be eliminated.
